Shop UK-made Hagon rear shocks for classic Triumph 500, 650 and 750 twins and Triumph and BSA triples. These Girling-style replacements have progressive chrome springs, a nitrogen-charged damper and three-position preload, and come in pairs with an adjuster spanner. Choose 12.4″ or 12.9″ eye-to-eye lengths in 100 lb or 110 lb spring rates. Need a different model? Use our custom order form below and we’ll order Hagons built for your bike and weight.
Looking for Other Hagon Shocks? Custom Orders Available Here.
As a US distributor of UK made Hagon shocks, we can custom order any make, model or year for you. Please fill out the form below and we will get back to you with pricing and further details. Once payment is complete, there are no refunds or exchanges.
Hagon shocks are made to order. There are no returns, refunds or exchanges.
Table of Contents
Hagon: From Speedway Frames to Shock Absorbers
Alf Hagon was an England international speedway rider and won 11 national grasstrack titles before founding Hagon Products in 1958 (Hagon Shocks). He started out building speedway and grasstrack frames in his mother’s garden shed, and from 1960 he ran the business from a former stable block in Leyton, East London (Wikipedia: Alf Hagon; Trakbytes Hall of Fame). Hagon frames used Girling shocks, and in 1977 Alf built what Motocross Action calls the first all-aluminum monocoque motocross frame. Alf was also a drag-racing record holder (Hagon Shocks).
In 1985, when Girling stopped making motorcycle shocks, Alf bought the former Girling suspension operation, including the stock, tooling and drawings. He didn’t buy the Girling name, so the shocks were sold as Hagon (Wikipedia: Alf Hagon; Trakbytes Hall of Fame). For more on Girling’s history, see Grace’s Guide.
From the 1980s, Hagon focused on twin shocks and rebuildable monoshocks. The company moved from its first shop on Leytonstone High Road to its factory at 7 Roebuck Road, Hainault, Essex. Alf’s son Martin, a European Grass Track Champion, runs the company today (Hagon Shocks). Hagon shocks are made at the Hainault factory, and road shocks are built for the rider’s weight and how the bike is used (Hagon Shocks: Manufacturing).
Hagon Shocks for Triumph Twins & Triples
Each pair has a black damper body, slimline chrome progressive springs, a double-sealed nitrogen cell, automatic compression and rebound damping, a hard chrome piston rod and a three-position preload adjuster. An adjuster spanner is included.
12.4-inch shocks
- Triumph 750 T140 and TR7, 1973–78, 100 lb (TBS-03-2004 SS): the standard length for 1973–78 Triumph 750 twins. They also fit unit 500 and 650 twins and Triumph and BSA triples from 1968 to 1975, lowering the rear by about 1/2″.
12.9-inch shocks
- Triumph 500 and 650 twins, 100 lb (TBS-03-3006 SS): the standard length for 1969–70 Triumph 650 twins and 1969–74 Triumph 500 twins. They also fit all unit 500, 650 and 750 Triumph twins up to 1978 and Triumph and BSA triples from 1968 to 1975.
- Triumph 500, 650 and 750 twins and Trident, 110 lb (TBS-03-3007 SS): Triumph 500 Daytona, Trophy and Tiger and 650 Bonneville, Tiger and Trophy from 1969, 750 T140 and TR7 from 1973 to 1978, and Triumph triples from 1969. The stiffer spring suits heavier riders or riding two-up.
None of these Hagon pairs fit the Norton Commando. Norton owners can use the Girling Norton Commando shocks or order custom Hagons with the form above.
Shop more Triumph suspension parts, BSA suspension parts and Norton suspension parts, or browse our Triumph T140 parts guide. Triple owners can read about the BSA Rocket 3 and Triumph Trident. For modern Hinckley Triumphs, visit our companion site, Modern British Iron.
Custom Order Hagon Shocks
We are a US distributor for UK-made Hagon shocks and can order Hagons for almost any motorcycle. Use the custom order form on this page and tell us:
- Your Hagon part number, if you know it
- Motorcycle make, model and year
- Rider weight, passenger weight and luggage weight in pounds
- How much of your riding is with a passenger
Hagon uses this information to choose the spring and damping for your bike (Hagon Shocks: Manufacturing). Our team will get back to you with pricing and details. Custom Hagon shocks are made to order, so once payment is complete they can’t be returned, refunded or exchanged.
How to Choose the Right Hagon Shocks
- Measure eye to eye. Measure your current shocks from the center of the top mounting eye to the center of the bottom eye. Most 1969 and later Triumph 500 and 650 twins use 12.9″, and the 1973–78 750 twins use 12.4″.
- Choose the spring rate. The 100 lb springs suit most solo riders. The 110 lb springs suit heavier riders, or riding with a passenger or luggage. For anything else, use the custom order form.
- Set the preload. Use the supplied spanner to adjust both shocks to the same setting, with the shocks fitted to the bike.
- Replace both shocks together. Shocks work as a matched pair.
- Check the mounting rubbers and hardware. Worn bushes and bolts spoil the ride of new shocks. See our Triumph rubber parts, Triumph hardware, Triumph frame fittings, BSA rubber spares, BSA hardware and suspension tools.
For background on how rear shocks work, see Wikipedia: Shock absorber and Motorcycle suspension. Need help choosing? Contact our team or call 720-570-7884.
Shop Hagon Shocks
Browse the Hagon pairs above, compare Girling shocks, or see all the brands we carry. Orders ship free to the lower 48 states, and weekday orders placed before noon Mountain Time ship the same day (Shipping and Returns). Every order earns Frequent Spanner Points when you are signed into your account.
Hagon Shocks FAQ
Where are Hagon shocks made?
Hagon shocks are made in the UK at Hagon Products’ factory in Hainault, Essex (Hagon Shocks: Manufacturing).
Is Hagon connected to Girling?
Yes. In 1985 Alf Hagon bought the former Girling motorcycle suspension operation, including the stock, tooling and drawings, but not the Girling name (Wikipedia: Alf Hagon). Hagon’s classic shocks are Girling-style replacements for original equipment.
Which Hagon shocks fit a Triumph T140 Bonneville?
The 12.4″ 100 lb pair (TBS-03-2004 SS) is the standard length for 1973–78 T140 and TR7 750 twins. The 12.9″ 110 lb pair (TBS-03-3007 SS) also fits these bikes and suits heavier riders or riding two-up, with a slightly taller ride height.
Which Hagon shocks fit a Triumph 650 or 500?
The 12.9″ pairs are the standard length for 1969–70 Triumph 650 twins and 1969–74 Triumph 500 twins. Choose 100 lb (TBS-03-3006 SS) for most solo riders or 110 lb (TBS-03-3007 SS) for heavier loads.
Do these Hagon shocks fit a Norton Commando?
No. The Hagon pairs we stock are not for Nortons. Commando owners can choose our Girling Norton Commando shocks or order custom Hagons with the form on this page.
Do Hagon shocks fit Triumph and BSA triples?
Yes. The 12.9″ pairs fit Triumph and BSA triples from 1968, and the 12.4″ pair also fits them if you want to lower the rear by about 1/2″.
Can Hagon build shocks for my weight?
Yes. Hagon builds road shocks for the rider’s weight and how the bike is used (Hagon Shocks: Manufacturing). Use our custom order form with your rider, passenger and luggage weights.
Can I return custom Hagon shocks?
No. Custom Hagon shocks are made to order, so once payment is complete there are no returns, refunds or exchanges. The stocked pairs on this page follow our normal return policy.
Do Hagon shocks come as a pair?
Yes. Each set is a pair of shocks with a preload adjuster spanner. Always replace both shocks together and set both to the same preload.
Do you offer free shipping on Hagon shocks?
Yes. Orders ship free to the lower 48 US states with no minimum order. Weekday orders placed before noon Mountain Time ship the same day.
